Model Number: B+RS600/K65HIntelligent TypeOutput Torrue: 6000NmInput & feedback signal: 4~20mAPower:220V/50Hz/1Ph,0.4KWTravel times:65sConnection:Foot-plate mounted Main Technical SpecificationsThe following specifications are principally for proportional regulation type; items 1,2,3,4, 5 and 6 are not applicable for remote control and switch type.1) Input signal: 4-20mA DC2) Input channel resistance: 250 Ω3) Number of input channel: 14) Basic error: 1%, 2.5%5) Backlash 1.5%6) Dead zone: 0.5-3% continuously adjustable (can be adjusted according to system requirement)7) Dumping character: Free of swing8) Voltage of power supply Three-phase 380V-50Hz Single-phase 220-50Hz9) Operation environment: Temperature: integrated type:-10-+55°C discrete type:-25-+70°C Humidity:below85%, free of corrosive atmosphere in the surrounding10) Protection class: In conformity with IEC145 IP65(i.e. for indoors or outdoors under the rain canopy, with an exception that discrete type for indoor installation.)11) Protection of signal interruption:At the option of fully-open, fully-closed or remain original position, which can be specified at time of ordering, it has been set to remaining original position mode when delivered.
