1. Product Usage: 3 Ton Medium Frequency Steel Smelting Furnace Our furnace have high melting efficiency, good energy saving effect, good metal component uniformity,less burning loss, speedy temperature rise, is suitable for all kinds of metal melting.
2. Product parameters:(specification)
3 Ton Medium Frequency Steel Smelting Furnace parameters:
| No. |
Items |
3T furnace |
Note |
| 1 |
Rate power |
2250KW |
|
| 2 |
Rated frequency |
0.5KHz |
|
| 3 |
Rated capacity |
3t |
Melting iron |
| 4 |
Power consumption/ton |
510±5% |
Concentrate materials, fulfill, count from the third batch, the rated temperature is 1500ºC. |
| 5 |
Melting time |
60 minutes |
KGPS-2250KW power parameters:
| No. |
Items |
Parameters |
Note |
| 1 |
Mode |
KGPS--2250KW/1KHZ |
Total power 2250KW |
| 2 |
Voltage |
660V |
|
| 3 |
Rectification |
6 pulse |
|
| 4 |
Input power frequency |
50Hz |
|
| 5 |
Output frequency |
0.5KHz |
|
| 6 |
Output power |
2250kw |
|
| 7 |
Transformer 2nd voltage |
660V |
|
KGPS-2250KW cooling system parameters:
| No. |
Item |
2250KW power supply |
Note |
| 1 |
Inlet temperature |
15ºC-40ºC |
|
| 2 |
Outlet temperature |
<55ºC |
|
| 3 |
Heat exchange medium |
Soft water |
Purchaser prepare |
3. 3T Induction Melting Furnace Items list:
| No. |
Items |
Specification |
Amount |
| 1 |
MF series power supply(rectification,inverter,capacitors) |
RT-2250KW |
One set |
| 2 |
3T MF steel shell furnace |
Including furnace structure, hydraulic system, inductor, magnet yoke, water knockout vessel, environmental dust collection lid, etc. |
One |
| 3 |
Connecting copper |
Connect capacitors and water cooled cable |
One set |
| 4 |
Water cooled cable |
Match 2250KW |
One set |
| 5 |
Hydraulic system |
Two pumps, one for backup |
One |
| 6 |
Hydraulic control system |
RT |
One |
| 7 |
Crucible |
RT |
1 |
| 8 |
Optional: Closed cooling system |
FBN150T(main engine,auxiliary engine,control box) |
One set |
4. Induction Melting Furnace Advantage:
3T Electric Induction Melting furnace for aluminum: 1) Constant power output, speedy melting, good electricity saving efficiency. 2) Zero-voltage sweep-frequency style start, adapts to requirement of frequency start. 3) Comprehensive protection functions, such as over currency protection, over voltage protection,current-limiting protection,voltage-limiting, water-break protection, and default protection, equipment runsreliably under premise of melting speed guarantee. 4) Easy to operate, suitable for all casting process.
5.Product transportation and packaging: Packaging & Delivery
Packaging Details:Plywood case packing with export standard for medium frequency induction melting furnaceDelivery Detail:Shipped in 30 days after payment
6. Rongtai company:
Shandong Rongtai was founded in 1997, focus on providing stable and efficient high-end inductionmelting solutions through 20 years. As a manufacturer, we have independent R&D capability. Twin-powersupply melting furnaces are our core products, our equipments can satisfy foundry industry's requirementof producing consistent and stable molten iron on an energy saving basis.
