The BLY-SFP4G3E is a 10/100/1000Mbps adaptive gigabit Ethernet Fiber Switch. It has three 10/100/1000Mbps UTP ports and four 1.25Gbps SFP fiber ports. It extends the transmission distance of a network from 100m via copper cables to 120km. Besides, there are also other advantages such as isolation protection, good data security, working stability and easy maintainance.
Specifications | |
---|---|
Standards |
IEEE802.3 10Base-T IEEE802.3u 100Base-TX/FX IEEE802.3ab 1000Base-T IEEE802.3z 1000Base-SX/LX IEEE802.3x Flow control IEEE802.1q VLAN IEEE802.1p QoS IEEE802.1d Spanning Tree |
Fiber Port |
Connector: SFP slot Data Rate: 1.25G Optical wavelength:850nm/1310nm/1490nm/1550nm Distance: 0~120km |
Copper Port |
Connector:RJ45 Data Rate: 10/100/1000M Distance: 0~100m UTP Type:UTP-5E or higher level |
Performance |
Processing Type : Store and Forward MAC Table Size: 1K Buffer Space: 1Mbit Back Bandwidth: 14G Time Delay:<20μs |
Power |
Input Voltage:AC100V~240V 50/60Hz Connector: DC Socket Working Voltage:5VDC Power Consumption: 1.8W~5W |
Environment |
Storage Temperature: -40 ~ +70 degrees Operating Temperature: -10 ~ +55 degrees Relative Humidity: 5-90% ( no condensation) |
Physical Characteristics |
Dimension: 160×84×26mm Weight:0.3kg Color: Metal, Black |
