Chinese supplier ceramic fiber cone
Posting date : Oct 12, 2016
Membership
Free Member Scince Oct 11, 2016
FOB Price
2USD/KG
Min. Order Quantity
1
Supply Abillity
100000TON
Port
any China port
Payment Terms
30%TT, 70% TT /LC
Package
CASE
Keyword :
Category
Contact
Molly
          0 likes
Product Detail
Company Info

Quick Detail
Place of Origin
China [CN]
Brand Name
HENGRUI
HS-CODE
6903-20
Package & Delivery Lead Time
Package
CASE
Specifications
Type of Certification
iso
Reference no.
06912Q11637ROM
Name.
ISO9001:2008
Issued By
KAIXIN CERTIFICATE BEIJING CO LTD
Start Date (validity period)
2016-06-20
End Date (validity period)
2019-06-19

Detailed Description
Descriptions:
Hengrui ceramic fiber module is made of Hengrui ceramic fiber blanket which is folded or cut by experienced professional technicians.We use special equipment for producing module to confirm the precise dimensions and keep smooth surface of module, and then be applied to the lining of various thermal equipment. The products have some characteristics such as reliable quality, quick installation, superior insulation properties.
Hengrui ceramic fiber module use the enhanced M-type anchors, which have greater strength, closer to the cold face. It can make sure the strength in high temperature. The fixed link was welding together with the high quality heat-resistance steel and stamping butterfly plate. The two round fixed link were embedded in the module system, enlarged the bearing area and ensured the firm of anchor system.

Characteristics:
  • Low bulk density,low thermal conductivity.
  • Resistance to heat-shock, ability to resist the scouring of airflow.
  • Excellent mechanical strength ,built-in anchor, safety performance.
  • Easy to install. after installing the lining form a seamless space, good insulation effect.
Applications:
  • Ceramic Industry:Tunnel kiln, shuttle kiln, roller kiln.
  • Petrochemical Industry: Atmospheric furnace, transforming furnace, coking furnace, cracking furnace, flue etc.
  • Iron and Steel Industry: Ladle cover, annealing furnace,rotary furnace,bell furnace,walking beam furnace,hot air and flue pipes etc.
  • Green energy industry:Waste incinerators, RTO exhaust treatment furnace, SCR environmental catalytic stove etc.
Technical Index:

Ceramic Fiber Module
HR1050
HR1260ST
HR1260HP
HR1350
HA
HR1430Zr
HR1600
PMF
Classification Temperature
(℃)
1050
1260
1260
1350
1430
1600
192kg/m3/at( )℃/24h
Linear Shrinkage Rate(%)
≤2.0
850℃
≤2.0
1000℃
≤2.2
1050℃
≤2.2
1100℃
≤2.5
1200℃
≤1.5
1450℃
Density(KG/M3)

172-240
172-240
172-240
172-240
172-240
172-240

Thermal Conductivity Rate(W/m.k)
400℃
0.08
0.08
0.08
0.08
0.08
-
600℃
0.15
0.15
0.15
0.12
0.12
0.12
800℃
0.22
0.20
0.19
0.18
0.16
0.15
1000℃
-
-
0.22
0.12
0.19
0.18

Chemical Composition(%)


Al2O3
42-44
45-46
47-49
52-55
38-44
72-75
Al2O3+SiO2
≥99.0
≥99.0
≥99.0
≥99.0
≥99.0
≥99.0
ZrO3
-
-
-
-
15-17
-
Other
≤1.0
≤1.0
≤1.0
≤1.0
≤1.0
≤1.0
The result is average value not guarantee value,fluctuate within the standard value, for more details about our products properties or technical support, please contact Hengrui Technical Department .
