Quick Detail
Place of Origin
Brand Name
Tobee
Model Number
150mm 12-24m3/h vertical circulation centrifugal pump
HS-CODE
8413-70
Package & Delivery Lead Time
Package
Wooden case
Delivery Lead Time
7days
Detailed Description
Size: 150mm
Capacity: 108-576m3/h
Head: 8.5-40mSpeed: 500-1000rpm
Eff.: 52%Power: Max.110kw
Handling solids: 45mm
Materials: High chrome alloy, Rubber, Polyurethane, Ceramic etc
Tobee® 150mm 12-24m3/h vertical circulation centrifugal pump are designed for every other tank, pit or hole-in-the-ground slurry handling situation, TP150SV pumps are available in various standard lengths to suit common sump depths, for very deep sumps or where high shaft speeds limit the length of the pump, a suction extension pipe can be fitted to the bottom inlet to extend the depth of the pump by up to 2 metres.
Design features:
• Fully Cantilevered - Eliminates submerged bearings, packing, lip seals, and mechanical seals that other vertical slurry pumps typically require.
• Impellers - Unique double suction impellers; fluid flow enters the top as well as the bottom. This design eliminates shaft seals and reduces thrust load on the bearings.
• Large Particle - Large particle impellers are also available and enable passing unusually large solids.
• Bearing Assembly - The maintenance friendly bearing assembly has heavy duty roller bearings, robust housings, and a massive shaft.
• Casing - The metal pumps have a heavy walled abrasive resistant Cr27Mo chrome alloy casing. Rubber pumps have a molded rubber casing adhered to sturdy metal structures.
• Column and Discharge Pipe - The metal pump columns and discharge pipes are steel, and the rubber columns and discharge pipes are rubber covered.
• Upper Strainers - Snap in elastomer strainers fit in column openings to prevent overly large particles and unwanted refuse from entering casing of the pump.
• Lower Strainers - Bolt-on cast strainers on the metal pump and molded snap-on elastomer strainers on the rubber pumps protect the pump from oversize particles.
| Tobee |
Warman |
Power P
(kw)
|
Capacity Q
(m3/h)
|
Head H
(m)
|
Speed n
(r/min)
|
Eff. η
(%)
|
Impeller dia.
(mm)
|
Max.particles
(mm)
|
Weight
(kg)
|
| TP(R)150SV |
150SV-SP(R) |
11-110 |
108-576 |
8.5-40 |
500-1000 |
52 |
450 |
45 |
1737 |
Tobee® Vertical Sump Pumps widely used for Mining, Mineral Processing, Sand and Gravel, Coal Prep, Chemical Slurry Service, Cyclone Feeds, Aggregate Processing, Wet crushers, SAG mill discharge, Fine Primary Mill Grinding, Tailings, Secondary Grinding, Bottom/fly ash slurries, Pulp And Paper, Food Processing, Cracking Operations, Gypsum slurries, Pipeline Transport, High Velocity Hydraulic Transport,Food Processing, Explosive Sludge In Metal Smelting, River And Pond Dredging, Heavy Refuse Removal, Larger Particle Or Low NPSHA Applications, Continuous (Snore) Sump Pump Operation, Abrasive Slurries, High Density Slurries, Large Particle Slurries, Sump Drainage, Wash down, Floor Drainage, Mixing, Iron Ore, Cooper, Diamond, Aluminum oxide, Gold, Kaolin, Phosphorite, Steel, Palm, Suger, Chemical, Power, FGD, Frac Sand Blending, Waste water, Flotation etc.Email:Sales2@tobeepump.com,web:www.tobeepump.com
